How to show the Status of a Binding

Sometimes it takes a while to retrieve the source data of a Binding. This is especially true if your application relies on data from a web service or rss feed on the web. In those situations, you will probably want to show information about the status of the binding to the user: Are you still waiting for the data to load? Was there an error when loading it? The Data Binding team has been discussing the possibility of adding a Status property on DataSourceProvider for V2, but until then, we have to come up with our own custom solutions. Today I will show you one way of displaying the status of a Binding in an application.

This application will start by binding to an invalid URL that returns a 404 error. I will show you how to get and display the exception error message when things don’t go as expected. I will then replace the source URL with a valid one, causing all the bindings to show the information I’m looking for. There are 3 status messages in this application: “Opening feed…”, “Ready” and the message of the exception. Here is the order in which I expect them to come up:

“Opening feed…” -> (404 error) -> “The remote server returned an error: (404) Not Found.” -> (Click button to fix source URL) -> “Opening feed…” -> (Valid data is loaded) -> “Ready” -> (Click Refresh button) -> “Opening feed…” -> (Valid data is loaded) -> “Ready”

The correct Uri that causes all bindings to succeed is http://xml.weather.yahoo.com/forecastrss?p=98052, which contains information about the weather conditions in Redmond. If you look at the xml in this source carefully, you will notice that several elements belong to one of the namespaces specified at the top of the file, as you can see below for the “condition” element:

    <rss version="2.0" xmlns:yweather="http://xml.weather.yahoo.com/ns/rss/1.0" xmlns:geo="http://www.w3.org/2003/01/geo/wgs84_pos#">
        (…)
    <yweather:condition text="Fair" code="34" temp="62" date="Sun, 23 Apr 2006 11:53 am PDT" />

How can we bind to the condition’s text in Avalon? We can do this by setting the XmlNamespaceManager property of XmlDataProvider to an XmlNamespacesMappingCollection, which contains one or more XmlNamespaceMappings. The mappings’ Uri has to map to the Uri in the source xml data, but the Prefix can be whatever you want (although I usually get the prefixes to map too to avoid confusion). We want to be independent of the source’s prefixes so that your Avalon application won’t break if the owners of the source decide to change their prefixes.

    <Window.Resources>
        <XmlNamespaceMappingCollection x:Key="namespace">
            <XmlNamespaceMapping Prefix="yweather" Uri="http://xml.weather.yahoo.com/ns/rss/1.0" />
        </XmlNamespaceMappingCollection>

        <XmlDataProvider (…) XmlNamespaceManager="{StaticResource namespace}" />
        (…)
    </Window.Resources>

Once you have the xml mappings in place, binding to an element within a namespace is as simple as specifying the namespace before the name of the element:

    <Label Grid.Row="2" Grid.Column="1" Content="{Binding XPath=item/yweather:condition/@text}" HorizontalAlignment="Left"/>

I want to display the correct status to the user in the StatusBar of the Window. I added a string property to the Window called “StatusMessage”, which will contain the strings “Opening feed…”, “Ready” or, in case of error, the error message of the exception. I then bound the StatusBar to this property as you can see below:

    <StatusBar DockPanel.Dock="Bottom">
        <StatusBarItem Name="statusBar">
            <StatusBarItem.Content>
                <Binding ElementName="win" Path="StatusMessage" />
            </StatusBarItem.Content>
        </StatusBarItem>
    </StatusBar>

The next step is to set the StatusMessage property to the correct status string. I started by defined two constants with the status messages that will be displayed when the page is opening and ready:

    private const string openingMessage = "Opening feed…";
    private const string readyMessage = "Ready";

Then I started thinking about which actions taken by the user cause the application to be in a particular state. If this becomes confusing for your application, I recommend drawing a state machine by identifying all states, actions and interaction between the two. I use this approach frequently when writing automation tests for data binding scenarios, especially when they’re complex. What actions cause this app to be in the opening state? Beginning the application, clicking the button to fix the URL and clicking the button to Refresh:

    public Window1()
    {
        this.StatusMessage = openingMessage;
        InitializeComponent();
    }

    void FixSource(object sender, RoutedEventArgs args)
    {
        xdp.Source = new Uri("http://xml.weather.yahoo.com/forecastrss?p=98052");
        this.StatusMessage = openingMessage;
    }

    void Refresh(object sender, RoutedEventArgs args)
    {
        xdp.Refresh();
        this.StatusMessage = openingMessage;
    }

What causes the application to be in the ready state? Getting new data. There is a DataChanged event handler in XmlDataProvider that can be used when we want to be alerted that new data was found:

    protected override void OnInitialized(EventArgs e)
    {
        base.OnInitialized(e);
        xdp = (XmlDataProvider)(this.Resources["404Provider"]);
        (…)
        xdp.DataChanged += DataChanged;
    }

    void DataChanged(object sender, EventArgs e)
    {
        this.StatusMessage = readyMessage;
    }

There is no event in XmlDataProvider specifically for informing us that the Error property changed. However, XmlDataProvider implements INotifyPropertyChanged and the PropertyChanged event is raised when Error changes. As a side note, keep in mind that a class implementing INotifyPropertyChanged is not a promise that it will raise PropertChanged when every single one of its properties changes: a class could have 10 properties, and only raise PropertyChanged for one of them. But in this case this is not a problem, XmlDataProvider does raise a PropertyChanged when Error changes. We can then provide a handler for PropertyChanged and set the StatusMessage to the error message when an exception is set to the Error property:

    protected override void OnInitialized(EventArgs e)
    {
        (…)
        ((INotifyPropertyChanged)xdp).PropertyChanged += SourceChanged;
        (…)
    }

    void SourceChanged(object sender, PropertyChangedEventArgs e)
    {
        if (e.PropertyName == "Error")
        {
            if (xdp.Error != null)
            {
                (…)
                this.StatusMessage = xdp.Error.Message;
            }
            (…)
        }
    }

I used the PropertyChanged handler to control the visibility of the Refresh and Fix buttons. This way, they only appear when it makes sense to click on them:

    void SourceChanged(object sender, PropertyChangedEventArgs e)
    {
        if (e.PropertyName == "Error")
        {
            if (xdp.Error != null)
            {
                refreshButton.Visibility = Visibility.Collapsed;
                fixButton.Visibility = Visibility.Visible;
                this.StatusMessage = xdp.Error.Message;
            }
            else
            {
                fixButton.Visibility = Visibility.Collapsed;
                refreshButton.Visibility = Visibility.Visible;
            }
        }
    }

And last, I used the setter of StatusMessage to display the hourglass cursor when the application is in the opening state:

    private string statusMessage;

    public string StatusMessage
    {
        get { return statusMessage; }
        set
        {
            statusMessage = value;
            if (statusMessage == openingMessage)
            {
                this.Cursor = Cursors.Wait;
            }
            else
            {
                this.Cursor = null;
            }
            OnPropertyChanged("StatusMessage");
        }
    }

Here are a few screenshots of different states of this application:

Here you can find the VS project with this sample code. This works with February CTP WPF bits.
